19" Cabinet IP55, 800 x 1000 mm, Side Cooling 1.0 - 1.9 kW
19" Cabinet 42U IP55 with Side Cooler 1.9 kW, Air Funnel
Item number:
KS55-4280GR.1,9A
EAN no.:
4049759236915
Product information for 19" Cabinet 42U IP55 with Side Cooler 1.9 kW, Air Funnel
IP55 cabinet KS55-4280GR.x with side-mounted cooling solution
3 power levels 1.0, 1.5 and 1.9 kW cooling capacity
Cooling device for industrial purposes at high environmental temperatures up to +55°C
Industrial-qualified steel sheet housings
Compact, rugged design and simple function
Electromechanical thermostat and fault indicating contact
Integrated condensate evaporator
Temperature selection directly at the device
Optional exhaust air funnel allows the direct discharge of waste heat through an exhaust hose (⊘ 150 mm) from the installation room
Noise level 67 dB(A)
Power supply 230 V / 50 Hz
Supplied completely ready-for-installation including prepared cabinet with all openings, sealings, cables etc.
3 power levels 1.0, 1.5 and 1.9 kW cooling capacity
Cooling device for industrial purposes at high environmental temperatures up to +55°C
Industrial-qualified steel sheet housings
Compact, rugged design and simple function
Electromechanical thermostat and fault indicating contact
Integrated condensate evaporator
Temperature selection directly at the device
Optional exhaust air funnel allows the direct discharge of waste heat through an exhaust hose (⊘ 150 mm) from the installation room
Noise level 67 dB(A)
Power supply 230 V / 50 Hz
Supplied completely ready-for-installation including prepared cabinet with all openings, sealings, cables etc.
Technical properties
| Alignment of cooling unit: | Left |
|---|---|
| Function master/slave: | False |
| Number of doors: | 2 |
| Sort of temperature control: | Thermostat |
| Voltage type: | AC |
Variants
| Item no. | Name | U | With Air Funnel Ø 150 mm | Cooling capacity, usable at 35 °C | Breite | Höhe | Tiefe | Betriebsspannung bei AC 50 Hz | Betriebsspannung bei AC 60 Hz | |
|---|---|---|---|---|---|---|---|---|---|---|
| KS55-4280GR.1,0A | 19" Cabinet 42U IP55 with Side Cooler 1.0 kW, Air Funnel | 42 | True | 1020 W | 995 mm | 2144 mm | 1000 mm | 230 – V | 230 – V | |
| KS55-4280GR.1,9 | 19" Cabinet 42U IP55 with Side Cooler 1.9 kW | 42 | False | 1960 W | 1037 mm | 2144 mm | 1000 mm | 230 – V | 230 – V | |
| KS55-4280GR.1,9A | 19" Cabinet 42U IP55 with Side Cooler 1.9 kW, Air Funnel | 42 | True | 1960 W | 1037 mm | 2144 mm | 1000 mm | 230 – V | 230 – V |
