SC Simplex Adapter with Plastic housing
Adapter SC Simplex OM4 erica violet
Item number:
53302.35
Product information for Adapter SC Simplex OM4 erica violet
SC Simplex Adapter with Plastic Housing
Technical properties
| Accessories: | Self-Tapping Screw |
|---|---|
| Conform to Standard: | IEC61754-4 |
| Construction type: | SC-Simplex |
| Dust cover: | True |
| Height: | 9.3 mm |
| Internal Shutter: | False |
| Length: | 27.6 mm |
| Material housing: | Plastic |
| Material sleeve: | Ceramics |
| Operating Temperature: | -40 – 75 °C |
| Storage Temperature: | -40 – 85 °C |
| Type of connector connection 1: | SC |
| Type of connector connection 2: | SC |
| Type of fastening: | Screw/snap in |
| Type of housing: | With flange |
| Width: | 22.0 mm |
