Draka GreenConnect Cat.7 Outdoor Cable S/FTP PE
![](https://www.efb-elektronik.de/media/bf/18/84/1652202152/Cat.7.jpg)
![](https://www.efb-elektronik.de/media/f8/77/b6/1652202160/PE.jpg)
Draka GreenConnect Cat.7 Outdoor Cable S/FTP PE,black, CPR Fca
Item number:
99731GC.500
Product information for Draka GreenConnect Cat.7 Outdoor Cable S/FTP PE,black, CPR Fca
Draka Green Connect complements the UC product range as a sustainable alternative for both standard copper cables and fiber optic cables. The outdoor cable CAT.7 S/FTP from the copper range of the UC-900 series, for example, achieves a reduction in CO2 emissions of up to 50 percent in the Green Connect version.
The pioneering Draka UC product range was developed on the basis of new research results in materials science and advanced manufacturing processes, according to the manufacturer. The focus is on reducing CO2 emissions, which should make an important contribution to the environment through an innovative choice of materials and energy-efficient manufacturing techniques. In addition, companies should benefit from greater investment protection.
Environmentally friendly innovation in copper & fiber optic data cables
CO2 reduction with Draka GreenConnect: Up to 60% for copper and at least 20% for fiber optic data cables
Use of up to 100% recycled copper
Use of recycled plastics
Optimized production with green electricity
Environmentally friendly drums
Local production: Made in Europe
The pioneering Draka UC product range was developed on the basis of new research results in materials science and advanced manufacturing processes, according to the manufacturer. The focus is on reducing CO2 emissions, which should make an important contribution to the environment through an innovative choice of materials and energy-efficient manufacturing techniques. In addition, companies should benefit from greater investment protection.
Environmentally friendly innovation in copper & fiber optic data cables
CO2 reduction with Draka GreenConnect: Up to 60% for copper and at least 20% for fiber optic data cables
Use of up to 100% recycled copper
Use of recycled plastics
Optimized production with green electricity
Environmentally friendly drums
Local production: Made in Europe
Technical properties
AWG-size: | 23/1 |
---|---|
Bending radius (dynamic): | ≥ 80 mm |
Bending radius (static): | ≥ 40 mm |
Cable: |
EN 50288-4-1 IEC 61156-5 |
Cable Construction: | S/FTP |
Cabling standards: |
EN 50173-1 EN 50288-4-1 IEC 61156-5 ISO/IEC 11801 |
Capacity to earth: | nom. 43 nF/km |
Category: | 7 |
Characteristic impedance: | 100 ± 25 Ohm |
Conductor category: | Kl.1 = single wire |
Conductor material: | CU, tinned |
Core identification: | colour |
Core insulation: | foam-skin PE |
Coupling attenuation: | ≥ 85 dB |
Delay skew: | ≤ 12 ns/100m |
Diameter conductor: | 0.56 mm |
Flame retardant: | No |
Halogen free (acc. EN 50267-2-2): | False |
Halogen free (according to EN 60754-1/2): | False |
Harmonised Standard: | EN 50575 |
Installation standard: | EN 50174 |
Insulation resistance (500V): | ≥ 5000 MOhm/km |
Jacket Material: | Polyethylene (PE) |
Loop resistance: | ≤ 165 Ohm/km |
Low smoke (according to EN 61034-2): | False |
Max. Freuqency: | 900 MHz |
NVP value: | 79 % |
Nominal cross section conductor: | 0.26 mm² |
Permitted cable outer temperature after assembling without vibration: | -55 – 60 °C |
Permitted cable outer temperature during assembling/handling: | -20 – 50 °C |
PoE: |
acc. to IEEE802.3af PoE acc. to IEEE802.3at PoE+ acc. to IEEE802.3bt 4PPoE |
Resistance unbalance: | ≤ 2 % |
Screen over stranding: | braiding |
Screen over stranding element: | foil + braid |
Separation class acc. EN50174-2: | D |
Stranding element: | Pairs |
Test voltage DC, 1 min: | 1000 V |
Transfer impedance at 1MHz: | ≤ 10 mOhm/m |
Transfer impedance at 10MHz: | ≤ 10 mOhm/m |
Transfer impedance at 30MHz: | ≤ 30 mOhm/m |
Transfer impedance at 100MHz: | ≤ 60 mOhm/m |
Transmission standards: | IEEE 802.3 10Mbit to 10Gbit |
UV resistance: | True |
