RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black
RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 20m
Item number:
K0993.20
EAN no.:
4049759009557
Product information for RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 20m
RJ45 patch cable Cat.5e S/UTP PVC TM11 1x90°
The Cat.5e patch cable has gold-plated contacts and meets the requirements for 2.5Gbit Ethernet.
Technical product properties
• Cat. 5e
• S/UTP cable with AWG26/7
• Jacket material made of polyvinyl chloride (PVC)
• Plug connection: RJ45 to RJ45
• Has gold-plated contacts
The jacket of the shielded patch cable is made of polyvinyl chloride (PVC) material. In addition, the cable offers the option of power supply via PoE according to IEEE802.3af, PoE+ according to IEEE802.3at and 4PPoE according to IEEE802.3bt.
The assignment of the TM11 plugs is according to TIA/EIA 568B and is 1:1 .
The Ethernet cable has a conductor material made of copper and is ideal for use in structured building cabling, industrial Ethernet and in data centers. A bandwidth of 100 MHz is possible.
The Cat.5e patch cable has gold-plated contacts and meets the requirements for 2.5Gbit Ethernet.
Technical product properties
• Cat. 5e
• S/UTP cable with AWG26/7
• Jacket material made of polyvinyl chloride (PVC)
• Plug connection: RJ45 to RJ45
• Has gold-plated contacts
The jacket of the shielded patch cable is made of polyvinyl chloride (PVC) material. In addition, the cable offers the option of power supply via PoE according to IEEE802.3af, PoE+ according to IEEE802.3at and 4PPoE according to IEEE802.3bt.
The assignment of the TM11 plugs is according to TIA/EIA 568B and is 1:1 .
The Ethernet cable has a conductor material made of copper and is ideal for use in structured building cabling, industrial Ethernet and in data centers. A bandwidth of 100 MHz is possible.
Technical properties
| AWG-size: | 26/7 |
|---|---|
| Allocation: | acc. TIA/EIA 568B |
| Anti-kink sleeve: | put-on |
| Area of Application: |
Data center Industrial Ethernet Structured cabling |
| Bandwidth: | 100MHz |
| Bending radius: | >20 mm |
| Cable construction: | 4x2 |
| Cable type: | S/UTP |
| Cable type acc. to Manufacturer: | Dätwyler CU 5502 flex |
| Cabling standard: |
ANSI/TIA-568-C.2 EN50173 ISO/IEC 11801 |
| Category: | 5e |
| Colour anti-kink sleeve: | black |
| Colour outer sheath: | black |
| Conductive shield: | 360° shield contact |
| Conductor Material: | Copper |
| Conductor resistance DC: | 113 Ω/km |
| Connector: | IEC 60603-7-3 |
| Connector type: | TM11 |
| Contacts: | Gold plated |
| Current Rating: | max. 1 A |
| Fire retardant version: | False |
| Halogen free: | False |
| Impedance: | 100 ±15 Ω |
| Jacket Material: | Polyvinylchlorid (PVC) |
| Length imprint: | False |
| Locking lever: | False |
| Loop resistance: | 225 Ω/km |
| Mating cycles: | 2000 |
| Model: | Shielded |
| NVP value: | 76 % |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Operating-/ tempering voltage: | max. 50 V DC |
| Outer diameter of the cable: | 5.1 mm |
| POE class: |
4PPoE acc. to IEEE802.3bt PoE+ acc. to IEEE802.3at PoE acc. to IEEE802.3af |
| Pin assignment: | 1:1 |
| Suitable for degree of protection (IP): | IP20 |
| Temperature Range (Installation): | 0 – 50 °C |
| Temperature Range (Operation): | -20 – 60 °C |
| Test voltage: | 1000 (V DC, 1min) core/core und core/screen |
| Transmission: | 2.5Gbit |
| Type of connector connection 1: | RJ45 8(8) |
| Type of connector connection 2: | RJ45 8(8) |
Variants
| Item no. | Name | Length | Längentoleranz | |
|---|---|---|---|---|
| K0993.0,25 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 0,25m | 0.25 m | ±5 % | |
| K0993.0,5 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 0,5m | 0.5 m | ±5 % | |
| K0993.1 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 1m | 1.0 m | ±5 % | |
| K0993.1,5 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 1,5m | 1.5 m | ±5 % | |
| K0993.3 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 3m | 3.0 m | ±5 % | |
| K0993.5 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 5m | 5.0 m | ±5 % | |
| K0993.10 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 10m | 10.0 m | ±5 % | |
| K0993.20 | RJ45 Patch Cord Cat.5e S/UTP PVC TM11 1x90° black 20m | 20.0 m | ±5 % |
