USB2.0 Desktop extension cable
USB desktop extension cable,1.5m, bw, A plug/A socket
Item number:
EB438V2
EAN no.:
4049759255961
Product information for USB desktop extension cable,1.5m, bw, A plug/A socket
USB desktop extension cable, length 1.5 metres
USB plug series A to USB socket Type-A
USB socket series A moulded in plastic base
Additional USB socket Type-A for power supply
USB plug series A to USB socket Type-A
USB socket series A moulded in plastic base
Additional USB socket Type-A for power supply
Technical properties
| 3D: | False |
|---|---|
| ARC: | False |
| Backwards compatible: | True |
| Beding radius (dynamic/static): | 25 mm |
| CEC: | False |
| Cable set: | False |
| Cable type (passive/active/optical): | active |
| Chip: | True |
| Connection type connection 1: | Plug |
| Connection type connection 2: | Jack |
| Connector 1 angulation: | 180° |
| Connector 2 angulation: | 180° |
| Contact Plating: | silver-plated |
| DSC: | False |
| Dust cover: | false |
| HDMI Power: | False |
| HDMI certified: | False |
| HEC (Ethernet channel): | False |
| Halogenfree: | No |
| Kink protection: | True |
| MSA: | False |
| MST: | False |
| Material Connector Housing: | PVC molded |
| Material Inner Conductor: | BC |
| Material jacket: | PVC |
| Max. mating cycles: | 5000 |
| Model: | Round Cable |
| Number of poles connection 1: | 5 |
| Number of poles connection 2: | 5 |
| Number of shieldings: | triple |
| Operating temperature: | -5 – 45 °C |
| PCIe Data transfer: | False |
| Printing: | AWM 2725 80℃ 30V VW-1 28AWG/1P AND 24AWG/2C USB CABLE |
| Scope of delivery: | 1xUSB Cable |
| Shielded: | True |
| Speed: | 480 Mbit/s |
| Storage Temperature: | -20 – 70 °C |
| Tensile strength (short/long): | 98,1 N |
| Type of connector connection 1: | USB-A |
| Type of connector connection 2: | USB-A |
| Type of packaging: | plastic bag |
| VESA certified: | False |
| VRR: | False |
| Various lengths cable set: | 1x1.5m |
| Version: | USB 2.0 High-Speed |
| Warranty: | 36 months |
| With termination resistor: | False |
| eARC: | False |
Safety instructions
Warning: Danger of tripping! If installed incorrectly, there is a risk of tripping.
